Installation, cont’d – Extron Electronics MLM-WB+ User Guide User Manual
Page 26
Installation, cont’d
MLM-WB • Installation
2-20
6.
Disconnect power (outside the MLM-WB) from the MLC, and also from the
input and output devices, and the host computer. The computer that was
used for set up in step four may be disconnected from the MLC.
7.
Secure the MLC’s external power supply to the top clamp plate, as shown
below.
Electrical Power
Source
Conduit
MLC 206 Power
Supply
(Use hook-and-loop
fasteners here.)
8.
Close the MLM-WB’s door and secure it to the outer enclosure with the
provided flat headed machine screws.
Extr
on
M
ed
ia
Lin
k
VCR
18 #440 Screws
(all around)
DI
SP
LA
Y
PO
W
ER
VO
LU
ME
MA
X/
MIN
VCR
DVD
Laptop
