EDID
Native
Resolution
Refresh Rate Type
Video
Format
Audio
33 800 x 600 60 Hz PC HDMI 2-Ch
34 1024 x 768 60 Hz PC HDMI 2-Ch
35 1280 x 768 60 Hz PC HDMI 2-Ch
36 1280 x 800 60 Hz PC HDMI 2-Ch
37 1280 x 1024 60 Hz PC HDMI 2-Ch
38 1360 x 768 60 Hz PC HDMI 2-Ch
39 1366 x 768 60 Hz PC HDMI 2-Ch
40 1400 x 1050 60 Hz PC HDMI 2-Ch
41 1440 x 900 60 Hz PC HDMI 2-Ch
42 1600 x 900 60 Hz PC HDMI 2-Ch
43 1600 x 1200 60 Hz PC HDMI 2-Ch
44 1680 x 1050 60 Hz PC HDMI 2-Ch
45 1920 x 1200 60 Hz PC HDMI 2-Ch
46 2048 x 1080 60 Hz PC HDMI 2-Ch
47 480p 60 Hz HDTV HDMI 2-Ch
48 576p 50 Hz HDTV HDMI 2-Ch
49 720p 50 Hz HDTV HDMI 2-Ch
50 720p 60 Hz HDTV HDMI 2-Ch
51 1080i 50 Hz HDTV HDMI 2-Ch
52 1080i 60 Hz HDTV HDMI 2-Ch
53 1080p 50/25 Hz HDTV HDMI 2-Ch
54 1080p 50 Hz HDTV HDMI 2-Ch
55 1080p 60/24 Hz HDTV HDMI 2-Ch
56 1080p 60 Hz HDTV HDMI 2-Ch
57 720p 50 Hz HDTV HDMI Multi-Ch
58 720p 60 Hz HDTV HDMI Multi-Ch
59 1080i 50 Hz HDTV HDMI Multi-Ch
60 1080i 60 Hz HDTV HDMI Multi-Ch
61 1080p 50/25 Hz HDTV HDMI Multi-Ch
62 1080p 50 Hz HDTV HDMI Multi-Ch
63 1080p 60/24 Hz HDTV HDMI Multi-Ch
64 1080p 60 Hz HDTV HDMI Multi-Ch
65 Output (autodetect)
66 User loaded slot 1
67 User loaded slot 2
68 User loaded slot 3
69 User loaded slot 4
NOTES:
• The inputs are loaded with a default EDID. VGA inputs 1 and 2 have EDID 14 and
digital inputs 3 to 6 have EDID 56.
• 2-Ch supports: 2-Ch LPCM audio
• Multi-Ch supports: 2-Ch LPCM, 8-Ch LPCM, all Dolby Digital formats and all DTS
formats
MPS 601 • Operation 17
