4-7 MGP 462 • Software Configuration and Control
X67 = Window transition effect type
1 = cut
2 = dissolve
3 = soft wipe up
4 = soft wipe down
5 = soft wipe right
6 = soft wipe left
7 = soft wipe center in
8 = soft wipe center out
9 = soft wipe square in
10 = soft wipe square out
11 = soft wipe curtain in
12 = soft wipe curtain out
13 = hard wipe up
14 = hard wipe down
15 = hard wipe right
16 = hard wipe left
17 = hard wipe center in
18 = hard wipe center out
19 = hard wipe square in
20 = hard wipe square out
21 = hard wipe curtain in
22 = hard wipe curtain out
X68 = Blanking adjustment range (0 - 255 lines)
X69
= Window preset (1 - 25)
X70 = Input preset (1 - 128)
X72 = Scaler refresh rate
1 = 50 Hz
2 = 60 Hz
3 = 72 Hz
4 = 96 Hz
5 = 100 Hz
6 = 120 Hz
X73 = Pixel phase (0-31)
X74 = Advanced picture settings range
(±128 auto-sensed value)
X75 = Window dissolve speed; 0 to 5 seconds in
0.1 second increments (01 = 0.1 second;
50 = 5.0 seconds)
X76 = Internal temperature in degrees Fahrenheit
X77 = Background image number (01 - 16)
Images must be named in the format
Bkgnn.bmp. nn = 01 - 16).
Images must be 24-bit bitmaps. Other
formats are not supported.
X78 = Image/Window shift value (zero location
is 2048, and limits are ± the output
resolution)
X79 = Window size. Windows can be 1/16 the
size of the output active area.
Maximum value is the active output
area.
X80 = Image size. Image can be 1/16 the size of
the input active area. Maximum value
is double the active output area for
200% zoom.
X81
= E-mail account user name. Maximum
length is 31 characters.
X82 = E-mail account password. Maximum
length is 31 characters. The MGP
responds with four asterisks (****) if a
password exists. If no password has
been set, the response is a blank field.
