FOX 3G DVC • Reference Information 28
Video
Signal type ..................................... SDI, HD-SDI, and 3G-SDI digital video signals
Data rates ...................................... 270 Mbps, 1.485 Gbps, 2.970 Gbps
Operation standards ....................... SMPTE 259M-C, SMPTE 292M, SMPTE 424M
Auto data rate lock ........................ Yes
Video input and loop through
Number/signal type ........................ 1 SDI (SMPTE 259M-C, 270 Mbps, HD-SDI [SMPTE 292M, 1.485 Gbps]), or
3G-SDI (SMPTE 424M, 2.97 Gbps) digital component video
Connector ...................................... 1 LC connector (fiber optic)
Data rates ...................................... 270 Mbps to 2.97 Gbps
Horizontal frequency ...................... 15 kHz to 100 kHz
Vertical frequency ........................... 24 Hz to 60 Hz
Resolution range ............................ NTSC, PAL, 720p, 1080i, 1080p
Video processing
Digital sampling ............................. 24 bit, 8 bits per color, 165 MHz standard
Colors ............................................ 16.78 million
Video output
Number/signal type ........................ 1 single link DVI-D
1 RGB, YUV / YPbPr
Connectors .................................... 1 female DVI-I
1 female 15-pin HD
Nominal level
TMDS ...................................... 1.0 Vp-p swing
Analog .................................... 1 Vp-p for Y of component video
0.7 Vp-p for RGB and for R-Y and B-Y of component video
Impedance
TMDS ...................................... 100 ohms
RGB ......................................... 75 ohms
Return loss ..................................... <-25 dB @ 100 MHz
DC offset ....................................... ±5 mV with input at 0 offset
Sync
Output type ................................... RGBHV, RGBS, RGsB, component video (bi-level or tri-level)
Output level ................................... 5.0 Vp-p for RGB
0.6 Vp-p for component video tri-level sync
0.3 Vp-p for component video bi-level sync
Output impedance ......................... 75 ohms
Output polarity ............................... Positive or negative (selectable)
Audio
Frequency response ........................ 20 Hz to 20 kHz, ±0.2 dB
THD + Noise ................................... 0.05% @ 1 kHz at nominal level, 0 dB gain
S/N ................................................. >100 dB at maximum output (unweighted)
Stereo channel separation .............. >80 dB @ 1 kHz
Audio input
Number/signal type ........................ 1 SDI embedded audio (SMPTE 272M, SMPTE 299M)
Connector ...................................... 1 LC connector (fiber optic)
Adjustment range .......................... -18 dB to 0 dB
