FOX 3G DVC • Operation

12

Overheating — The

Temperature Overload!!!

screen is added to the default cycle

if the internal temperature of the unit exceeds 65 °C (149 °F).

TEMPERATURE
OVERLOAD!!!

INPUT

HDSDI 1.485G

INPUT

720p @59.94Hz

5 sec.

5 sec.

5 sec.

Figure 12.

Example of the Default Cycle When the Unit Is Overheating

Video muted — The input resolution and rate screen (second screen of the default
cycle) displays a blinking asterisk (*) on both sides of the word

INPUT

. The asterisks

disappear when the video is unmuted (the asterisks also appear on the

INPUT

NO

SIGNAL!

screen during video muting).

INPUT

HDSDI 1.485G

* INPUT *

720p @59.94Hz

5 sec.

5 sec.

Figure 13.

Example of the Default Cycle When the Video Is Muted

To mute and unmute the video, see the

Video Mute SIS commands

in the “Remote

Configuration and Control” section.

Menus on the LCD Screen

The FOX 3G DVC menus that are displayed on the LCD screen enable you to configure
and operate the converter. The menu navigation buttons (Menu and Next) are located to
the right of the LCD screen. Press these buttons to cycle through the available menus and
submenus, and use the horizontal and vertical Adjust knobs to select options.
This section provides information on the menus and submenus, including any procedures
that are initiated from them.

Menu System Overview

The menu system consists of three menus, which have submenus that enable you to make
desired adjustments (see the

menu flow diagram

on the next page).

Using the menus

1.

To access the menu system, press the Menu button. The first menu (

OUTPUT

CONFIG

) is

displayed on the LCD screen.

2.

Select other menus by repeatedly pressing the Menu button until the desired menu is
displayed.

3.

Press the Next button repeatedly to cycle through the submenus for the selected menu.

4.

When the desired submenu is displayed, rotate the horizontal ([) or vertical ({) Adjust
knob clockwise or counterclockwise to cycle through the submenu options. If you want
to return to a menu from within one of its submenus, press Menu.

5.

When the desired option is displayed, do one of the following to select it:

Press Next to display another submenu.

Press Menu repeatedly until the

EXIT

MENU

PRESS

NEXT

screen appears, then press

the Next button to return to the default cycle.

Wait until the LCD screen returns to the default cycle (approximately 30 seconds).
