FOX 3G DVC • Operation 13
NOTE: The menus time out and the default cycle is displayed after 30 seconds of
inactivity; however, any selections you made with the Adjust knobs are saved
and remain in effect until you change them or reset the unit to factory defaults
(see “
Resetting ,” later in this section).
Menu flow diagram
The flow diagram below shows the menus that are displayed in the front panel LCD screen
and the order in which they appear when you repeatedly press the Menu button.
AUDIO
CONFIG
Menu
Menu
30 sec.
Default
Cycle
Menu
Next
EXIT MENU
PRESS NEXT
OUTPUT
CONFIG
30 sec.
30 sec.
Menu
ADVANCED
CONFIG
30 sec.
Menu
Figure 14. Main Menu Flow Diagram
