42 M795GB0503
Data Transmitter 795
SW ver. 830434
LOG, 24 h á 5 min: REG. NO.: VALUE: DESCRIPTION:
Analogue input 1 288 The lowest logged value.
Analogue input 1 575 The oldest logged value.
Analogue input 2 576 The lowest logged value.
Analogue input 2 863 The oldest logged value.
Analogue input 3 864 The lowest logged value.
Analogue input 3 1151 The oldest logged value.
Analogue input 4 1152 The lowest logged value.
Analogue input 4 1439 The oldest logged value.
704 level 1440 The lowest logged value.
704 level 1727 The oldest logged value.
LOG, 24 h á 1 h: REG. NO.: VALUE: DESCRIPTION:
D1 1 pulse counter 1728-1751 24 x time difference counters.
D1 2 pulse counter 1752-1775 24 x time difference counters.
D1 3 pulse counter 1776-1799 24 x time difference counters.
D1 4 pulse counter 1800-1823 24 x time difference counters.
D1 5 pulse counter 1824-1847 24 x time difference counters.
D1 6 pulse counter 1848-1871 24 x time difference counters.
D1 7 pulse counter 1872-1895 24 x time difference counters.
D1 8 pulse counter 1896-1919 24 x time difference counters.
D1 9 pulse counter 1920-1943 24 x time difference counters.
D1 10 pulse counter 1944-1967 24 x time difference counters.
D1 11 pulse counter 1968-1991 24 x time difference counters.
D1 12 pulse counter 1992-2015 24 x time difference counters.
D1 1 time counter 2016-2039 24 x time difference counters in minutes.
D1 2 time counter 2040-2063 24 x time difference counters in minutes.
D1 3 time counter 2064-2087 24 x time difference counters in minutes.
D1 4 time counter 2088-2111 24 x time difference counters in minutes.
D1 5 time counter 2112-2135 24 x time difference counters in minutes.
D1 6 time counter 2136-2159 24 x time difference counters in minutes.
D1 7 time counter 2160-2183 24 x time difference counters in minutes.
D1 8 time counter 2184-2207 24 x time difference counters in minutes.
D1 9 time counter 2208-2231 24 x time difference counters in minutes.
D1 10 time counter 2232-2255 24 x time difference counters in minutes.
D1 11 time counter 2256-2278 24 x time difference counters in minutes.
D1 12 time counter 2280-2303 24 x time difference counters in minutes.
Limit 1 (high) pulse 2304-2327 24 x time difference counters.
Limit 2 (high) pulse 2328-2351 24 x time difference counters.
Limit 3 (high) pulse 2352-2375 24 x time difference counters.
Limit 4 (high) pulse 2376-2399 24 x time difference counters.
Limit 1 (low) pulse 2400-2423 24 x time difference counters.
Limit 2 (low) pulse 2424-2447 24 x time difference counters.
Limit 3 (low) pulse 2448-2471 24 x time difference counters.
Limit 4 (low) pulse 2472-2495 24 x time difference counters.
Limit 1 (high) time 2496-2519 24 x time difference counters in minutes.
Limit 2 (high) time 2520-2543 24 x time difference counters in minutes.
Limit 3 (high) time 2544-2567 24 x time difference counters in minutes.
Limit 4 (high) time 2568-2591 24 x time difference counters in minutes.
Limit 1 (low) time 2592-2615 24 x time difference counters in minutes.
Limit 2 (low) time 2616-2639 24 x time difference counters in minutes.
Limit 3 (low) time 2640-2663 24 x time difference counters in minutes.
Limit 4 (low) time 2664-2687 24 x time difference counters in minutes.
704 output 1 pulse 2688-2711 24 x time difference counters.
704 output 2 pulse 2712-2735 24 x time difference counters.
704 output 3 pulse 2736-2759 24 x time difference counters.
704 output 4 pulse 2760-2783 24 x time difference counters.
704 output 1 time 2784-2807 24 x time difference counters in minutes.
704 output 2 time 2808-2831 24 x time difference counters in minutes.
704 output 3 time 2832-2855 24 x time difference counters in minutes.
704 output 4 time 2856-2879 24 x time difference counters in minutes.
795 stormflow pulse 2880-2903 24 x time difference counters in minutes.
704 pumped value P1 2904-2927 24 x time difference counters in minutes.
704 pumped value P2 2928-2951 24 x time difference counters in minutes.
704 pumped value P3 2952-2975 24 x time difference counters in minutes.
704 pumped value P4 2976-2999 24 x time difference counters in minutes.
704 pumped value total 3000-3023 24 x time difference counters in minutes.
SPECIAL REGISTERS: REG. NO.: VALUE: DESCRIPTION:
795 Log interval in sec. 3068 Read only
795 Log Pointer 3069 Read only
Software Release 3070 Read only
Data Page 3071 READ and WRITE Register. 0=standard Comli 1= 704 COMLI, 2=795 Setup parameters,
3=Datalogger for 704 level, 4-7=Datalogger for Analogue 1-4
