24 M795GB0503
Data Transmitter 795
SW ver. 830434
Eks.: Data Transmitter ID 001 is supposed to
remote control Data Transmitter ID 003:
Enter the ID number "003" into Data
Transmitter 001.
If the receiving unit is another Data Transmitter
which is communicating via telephone/GSM mo-
dem, the telephone number to the Data Trans-
mitter is entered here.
Ex.: Data Transmitter no. 1 is supposed to
remote control the Data Transmitter no. 3:
Enter the telephone number "45560656"
into Data Transmitter no. 1.
If the receiving unit is a Data Transmitter
belonging to another cluster of Data Transmitters,
the ID number / telephone number belonging to
the Master in the cluster should be entered
followed by the ID number of the desired Data
Transmitter in the cluster.
Eks.: Data Transmitter 001 in the lower cluster is
remote controlling Data Transmitter 003 in
the upper cluster: Enter telephone / ID-
number "45560656-003" into Data Trans-
mitter no. 001.
Please note, that only a Master Data Transmitter
can directly remote control other Data Transmit-
ters belonging to other clusters.
Use the numeric keys and confirm with ENTER.
11.4.4 Receiver's output
Select the desired digital output on the
interlocked Data Transmitter:
Use the arrow keys and confirm with ENTER.
