31 M795GB0503
Data Transmitter 795
SW ver. 830434
17 Factory settings
Main functions: Settings: Main functions: Settings:
Language English No. of rings before answer 1
Autochange summer/winter time No ID no. for data transmitter 1
Access code No Automatic alarm reset No
Averaging of analog inputs No Call on auto alarm reset No
Datalogging interval 00:30 (30 sek.) Start time for operational report 00:00
Tone/Pulse dialing Tone 795 telephone number -
Alarm call on power failure No SMSC telephone number -
Analogue inputs: AI1: AI2: AI3: AI4:
0-20mA/4-20mA 4-20 mA 4-20 mA 4-20 mA 4-20 mA
Scaling @ 0/4 mA 0 0 0 0
Scaling @ 20 mA 9999 9999 9999 9999
High limit yes/no No No No No
High limit value 999 999 999 999
High limit operational/alarm Operational Operational Operational Operational
Signal delay (sec.) 0 0 0 0
Dialout on high limit No No No No
Low limit yes/no No No No No
Low limit value 0 0 0 0
Low limit operational/alarm Operational Operational Operational Operational
Signal delay (sec.) 0 0 0 0
Dialout on high limit No No No No
Divisor 0 0 0 0
Digital inputs: NO/NC: Operational/Alarm Alarm call Signal delay:
Digital indgang nr. 1-8/12/16 NO Operational No 0
Digital outputs: NO/NC: Time/Fixed: On time: Time before start:
DO no. 1-4/8 NO Time 10 sec. 5 sec.
Interlock: Setting: (Station 1-9)
Interlock of this station No
Interlock interval 5 min + 0
Start of interlock DI 1
Stop of interlock DI 1
Receivers tel/ID no. 0
Receivers output DO 1
Pump control: Setting:
704 connected No
704 output alarm call No
704 system errror alarm call No
795 no. of pumps 0
795 start level 1 0
795 stop level 1 0
795 level 2 in use No
795 start level 2 0
795 stop level 2 0
795 alternation No
Telephone list:
Type (PC/pager/ Telephone Pager/SMS
Pause in min.:
Tel/SMS): number: message:
Telephone no. 1-9 Available 0 0
