38 M795GB0503
Data Transmitter 795
SW ver. 830434
ONLINE VALUES: I/O NO.: DESCRIPTION:
116 read/write
117 read/write
Internal flag 1 140 read/reset The Combi alarms are a combination of 2 signals ANDed together. The programming of the
Combi alarms is made on the MJK Data transmitter 795.
Internal flag 2 141 read/reset The programming of the Combi alarms is made on the MJK Data transmitter 795.
Internal flag 3 142 read/reset All the Combi Alarms are READ or RESET bits
Internal flag 4 143 read/reset
Internal flag 5 144 read/reset
Internal flag 6 145 read/reset
Internal flag 7 146 read/reset
Internal flag 8 147 read/reset
Test alarm 150 read/reset I/O150 activates a 2 min. timer which activates I/O 107
ONLINE VALUES: REG. NO.: VALUE: DESCRIPTION:
Digital outputs 1-8 0 0-255 The outputs can be read and set (0-255)
Digital inputs 1-8 1 0-255 Inputs can be read (0-255)
Digital inputs 9-16 2 0-255 Option
Alarm inputs 1-8 3 0-255 Read an reset (0-255)
Alarm inputs 9-16 4 0-255 Option
Limit Switches 1-4 5 0-255 Read (0-255)
Alarm limits 1-4 6 0-255 Read and reset (cancelled) (0-255)
704 output/alarm 1-4 7 0-255 (Outputs can only be controlled bit-wise !)
Control signals 8 Read and reset (795 voltage failure and 704 system error)
9
Cluster and ID no. 10 0-255 Read
Status for internal flags 11 Read
Alarms from internal flags 12 Read and reset
Test register 13 Writing 1 to this register activates a test procedure.
14
Password 15 Enter 1795 to enable change in the setup page (page 2)
Analogue indgang 1 16 0-9999
Analogue indgang 2 17 0-9999
Analogue indgang 3 18 0-9999
Analogue indgang 4 19 0-9999
795 ID no. 20 1-247
704 level 21 0-1000 (0-255)
795 stormflow m³/h 22 0-65535
Extended log interval 23 0=30 sec. 1=1 min. 2=5 min. 3=10 min. 4=30 min. 5=1 hour
704 P1 start level 24 0-1000
704 P2 start level 25 0-1000
704 P3 start level 26 0-1000
704 P4 start level 27 0-1000
704 P1 stop level 28 0-1000
704 P2 stop level 29 0-1000
704 P3 stop level 30 0-1000
704 P4 stop level 31 0-1000
Al1 high limit value 32 0-9999 Analog limits can be read and set
Al2 high limit value 33 0-9999
Al3 high limit value 34 0-9999
Al4 high limit value 35 0-9999
Al1 low limit value 36 0-9999
Al2 low limit value 37 0-9999
Al3 low limit value 38 0-9999
Al4 low limit value 39 0-9999
ID number from Inter, Master 40
Interlock output 41
42
43
795 P1 start level 44 0-9999
795 P2 start level 45 0-9999
795 P1 stop level 46 0-9999
795 P2 stop level 47 0-9999
