H-3531
SDI-12 Command and Response Protocol 5-15
5.14 Extended Read/Write 0-5V Output Enable
The H-3531 FlashLite™ scales the current Stage data to drive the 0-5V analog output. This
extended command is for reading/writing the 0-5V output enable. When the enable value is set to
a ‘1' then the 0-5V analog output is enabled and when it is set to a ‘0' then the 0-5V analog output
is disabled.
Command Response Description
“aXRVE!” “a0011” Read 0-5V enable
“aXWVEd!” “a0021” Write 0-5V enable
Where: a is the sensor address ("0-9", "A-Z", "a-z", "*", "?").
XRVE are upper case characters.
XWVE are upper case characters.
d is the new enable value(0/1)
Example of a H-3531 Extended "Read 0-5V Enable" command:
Command
Response Time Values Description
"aXRVE!" "a0011" 1 sec 1 Read 0-5V Enable
Command Response Description
"aD0!" "a+0" 0-5V out disabled
Example of a H-3531 Extended "Write 0-5V Enable" command:
Command
Response Time Values Description
"aXWVE1!" "a0021" 2 sec 1 Enable 0-5V out
Command Response Description
"aD0!" "a+1" 0-5V out enabled
