1-2 Introduction

H-3531

1.1 Unpacking
The following is a list of items you should have received:

ATER

LOG H-3531 FlashLite™ pressure transducer

Main interface cable

RS232 communication cable.(optional)

Owner's Manual

1.2 Check The Model Number
Before installing your new W

ATER

LOG H-3531 FlashLite™, check the information on the label

of the sensor enclosure. Check the model number, the range, and the output type to be sure that
you have received the instrument you ordered. The label will look similar to the following:

This example shows that the W

ATER

LOG H-3531 FlashLite™ measures pressure within the

range from zero to 15-psi.

H-3531

Model

FlashLite Pressure Sensor

S/N

1103

Range:

0-15 PSI (34.6' H20)

Output:: SDI-12, RS232, 0-5V, and

Quadrature
