4-8 Simple RS-232 Menu Interface
H-3531
4.4.5.3 B - Baud Rate
This option is for displaying or changing the current baud rate for the RS-485
Modbus communications port. Pressing the B key will show the following
message at the bottom of the screen.
Enter Option >Modbus Baud Rate [9600]
Press the up or down key to change the baud rate selections and then press the
ENTER key to accept the selection.
4.4.5.3 P - Parity
This option is for displaying or changing the current parity for the RS-485 Modbus
communications port. Pressing the P key will show the following message at the
bottom of the screen.
Enter Option >Modbus Parity [Even]
Press the up or down key to change the parity and then press the ENTER key to
accept the selection.
4.4.6 D - Reset to Defaults
This option will reset the H-3531 FlashLite™ back to factory user defaults. The following
message will be displayed.
Enter Option >Resetting to Defaults...
4.5 Sensor Output Setup Menu
This setup menu is for
viewing or editing the current
settings for the 0-5v analog
output and 4-20mA output.
Sensor Output Setup Menu
0-5v Output Options:
Slope = +.144506
V - 0-5v Output: Off
H - Max Stage: +34.60
L - Min Stage: +0.00
4-20mA Output Options:
Slope = +.462427
M - Max Stage: +34.60
N - Min Stage: +0.00
Quad Output Options:
Q - Quad Output: Off
U - Update Outputs
Enter Option >
