H-3531
Simple RS-232 Menu Interface 4-11
4.6.1 Tank Pressure
This is a bubbler status value and cannot be edited by the user. This is the tank pressure
value that was measured by the H-355.
4.6.2 Line Pressure
This is a bubbler status value and cannot be edited by the user. This is the line pressure
that was measured by the H-355.
4.6.3 B - Bubble Rate
This option is for displaying the current bubble rate and also for editing the bubble rate.
After pressing the B key the user will see the following prompt at the bottom of the menu.
Enter Bubble Rate(30-120)[ ]
Then the user can enter in the new bubble rate and press the Enter key to input the value.
After the bubble rate is entered the screen will refresh with the bubble rate changed. If the
user does not want to edit the bubble rate then press the ESC key to abort. The user can
change the bubble rate from 30 to 120 bubbles/minute.
4.6.4 P - Purge Pressure
This option is for displaying the current purge pressure and also for editing the purge
pressure. After pressing the P key the user will see the following prompt at the bottom of
the menu.
Enter Purge Pressure(15-80)[ ]
Then the user can enter in the new purge pressure and press the Enter key to input the
value. After the purge pressure is entered the screen will refresh with the purge pressure
changed. If the user does not want to edit the purge pressure then press the ESC key to
abort. The user can change the purge pressure from 15 to 80 psi.
4.6.5 D - Purge Duration
This option is for displaying the current purge duration and also for editing the purge
H-355 Bubbler Setup Menu
Tank Pressure: +2.44
Line Pressure: -.09
B - Bubble Rate: +60
P - Purge Pressure: +40
D - Purge Duration: +50
A - Auto Purge: Off
T - Purge Threshold: +20
M - Manual Purge
U - Update All Values
Enter Option >
