46
4
MAINTENANCE PROCEDURES
AND TROUBLESHOOTING
4.1 LUBRICATION INSTRUCTIONS
No lubrication is required.
4.2 TROUBLESHOOTING PROCEDURES
4.2.1. TROUBLESHOOTING
Table 4.1 lists common malfunctions that may occur with the equipment. Perform the tests, inspections
and corrective actions in the order they appear in the table.
This table does not list all of the malfunctions that may occur with your device, nor does it include all
tests, inspections, or corrective actions that may be necessary to identify and fix defects. If you experi-
ence an equipment malfunction that is not listed, or suggested corrective actions do not correct the
fault, please contact Customer Support.
TABLE 4-1. OPERATOR’S TROUBLESHOOTING
MALFUNCTION TEST OR INSPECTION CORRECTIVE ACTION
1. Monocular fails to activate. Visual.
Check for defective, missing or
improperly installed battery.
Turn the power switch to RESET/ OFF,
and then turn it ON.
Replace battery or install it correctly.
2. IR source fails to activate. In a dark location with system turned
on, activate IR source.
Visually check IR source operation;
scene should brighten.
If IR source still fails to activate, please
contact Customer Support.
3. IR source indicator fails to
activate.
Visual. Please contact Customer Support.
4. Poor image quality. Check objective lens or eyepiece lens
focus.
Check for fogging or dirt on objective
lens or eyepiece lens.
Refocus.
Clean lens surfaces per paragraph 4.2.
