23
ITEM
NO. INTERVAL CHECK/SERVICE
PROCEDURE NOT FULLY MISSION CAPABLE IF...
12 Before/
After Socket Inspect for dirt, dust, or corrosion.
Insert monocular latch into socket to
verify secure attachment of monocu-
lar to headmount. If necessary, clean
socket with water. Damaged, latch won’t lock or
is too loose.
13 Before
/After Eye Relief
Adjustment Press the eye relief adjustment and
check for free motion. Inspect for
damage. Binding, damaged or non-
operational slide mechanism.
14 Before
/After
Straps
HELMET MOUNT
Inspect for cuts, tears, fraying, holes,
cracks, or defective fasteners.
Damage causes straps to be
unserviceable.
15 Before
/After Socket Inspect for dirt, dust, or corrosion.
Insert monocular latch into socket to
verify secure attachment of mon-
ocular to helmet mount. If necessary,
clean socket with water. Damaged, latch won’t lock or
is too loose.
16 Before
/After Fore-and-Aft
Adjustment Press the two side buttons on plastic
mount or depress side lever on metal
mount and check for free motion.
Inspect for damage. Binding, damaged or non-
operational slide mechanism.
17 Before
/After Headmount/
Helmet
Mount
Adapter
MOUNTING ADAPTERS
Inspect for dirt, dust or corrosion.
Insert into headmount or helmet
mount socket to verify secure attach-
ment.
Damaged, will not latch
securely.
18 Before
/After Weapon
Mount
Inspect for dust, dirt or corrosion.
Damaged, will not mount to
monocular or will not mount
to rail.
19 Before/
After
ACCESSORIES
CAUTION :
IThe coating on the demist shield
can be damaged if cleaned while
wet or if cleaned with wet lens pa-
per. Clean only when the demist
shield is dry and only with dry pa-
per.
Inspect for dirt, dust, scratches or
damage. If necessary, clean when
shield is dry (use dry lens tissue only). Damage or scratches hinder
vision when the monocular is
turned on.
20 Before
/After Sacrificial
Window Inspect for dirt, dust, scratches or
damage. If necessary, clean per para-
graph 4.2. Damage or scratches hinder
vision when the monocular is
turned on.
TABLE 3-1. CONTINUED
