19
NOTE :
The gain control function is not available with the 6015 model.
NOTE :
Indicators showing that the battery is low and that the IR is active are both visible in the eye-
piece lens.
TABLE 3-1. MONOCULAR CONTROLS AND INDICATORS
CONTROLS AND INDICATORS FUNCTIONS
Power Switch
Controls the monocular and IR source, ON or OFF.
RESET/ OFF
Same as system OFF. Also resets monocular after high light
cut-off.
ON Monocular activated.
IR/ PULL
Turn the knob clockwise to momentarily activate the IR source.
For continuous operation of the IR, pull and turn the knob
clockwise from the ON position.
CAUTION :
Do not use excessive force when operating the power switch.
Low Battery Indicator
The low battery indicator will blink on and off when there are less than 30
minutes of battery life remaining. It is visible through the eyepiece, just out-
side the intensified field-of-view.
IR Source On Indicator
The IR Source On indicator will blink when the IR is activated. It is visible
through the eyepiece just outside the intensified field-of-view.
Gain Control
(PVS-14 only) Adjusts the system gain from a minimum value of approximately 25 to a
maximum value greater than 3,000.
Objective Focus Focuses objective lens. Adjusts for sharpest image of viewed object.
Diopter Adjustment
Focuses eyepiece lens for use without a need for glasses. Adjusts for sharpest
image of intensifier screen.
Eye Relief Adjustment Adjusts the distance between your eye and the monocular.
Latch
Latch used for separation of monocular from head-mount/ helmet mount
adapter.
Battery Polarity Indi-
cators
This feature, molded into the battery housing, shows the proper orientation
of the battery. Some versions have a bubble molded into the top of the bat-
tery house that indicates polarity.
