15
c. Helmet Mount
The helmet mount (Figure 2-1) secures the monocular to the Personal Armor System Ground Troops
(PASGT) helmet, allowing freehand support for use with a weapon, protective mask and/ or other pur-
poses in which freehand operation is required. The new helmet mount is made of a ruggedized metal,
unlike the older version, which is made of plastic.
d. Headmount/Helmet Mount Adapter
The headmount/ helmet mount adapter (Figure 2-1) is attached to the monocular to allow use with the
headmount or helmet mount. It allows mounting in front of the left or right eye.
e. Weapon Mount
The weapon mount (Figure 2-1) adapts the monocular to the receiver rail as configured for the modular
weapon system kit.
f. Carrying Case
The carrying case (Figure 2-3) is provided for transportation and protection of the monocular, head-
mount, battery and accessories. Two slide keepers are provided for belt attachment; three D-rings are
provided for shoulder and leg strap attachment. A carrying case strap is also provided, and can be at-
tached to the two D-rings on the back of the carrying case.
g. Shipping and Storage Case
The NVMPS is supplied in a shipping and storage case (Figure 2-3).
h. AIM PVS14 Kit
AIM Advanced Integrated Mount (Figure 2-5) allows the user to quickly convert the PVS-14 into a weap-
on sight. The Kit includes the AIM and bracket for installing PVS-14 onto the AIM.
i. Double Lever-Lock quick Release Picatinny Mount Adapter #26
Small arms adapter that allows the PVS-14 to be mounted on a weapon using Picatinny Mil 1913 rail
(Figure 2-5).
j. Bracket PVS14 #62
Allows the PVS-14 to be mounted on the Quick Release Picatinny Mount Adapter (Figure 2-5).
2.2.3. EqUIPMENT DATA
The following tables provide information pertaining to the operational, electrical, mechanical, optical,
and environmental characteristics of the monocular.
TABLE 2-1. OPERATOR ADJUSTMENT LIMITS
ITEM LIMITS
Diopter Focus +2 to -6 diopters
Objective Focus 25cm (9.8”) to infinity
TABLE 2-2. ELECTRICAL DATA
ITEM DATA
Power Source Battery (1.5 Vdc max ea.)
Battery Requirements 1 AA Alkaline or 1 AA 1.5 Vdc Lithium L91
