The clamping system of the AIM is the same as is seen on the QRM. To mount the MUNVM to a weapon
with an AIM, see Part 3.3.13 of this Manual. This section describes mounting instructions and proce-
dures for the QRM.
MUNVM installed onto the AIM is shown in Figure 3-22.
For more information on the use of an AIM, see the AIM Operation Manual.
3.4 OPERATING PROCEDURES
This section contains operating procedures for using the NVMPS as hand-held, head-mounted, helmet-
mounted or weapon-mounted monocular. Before operating the monocular, verify that all steps in sec-
tion 3.3.3, Assembly and Preparation for Use, have been read and performed.
3.4.1. HAND-HELD OPERATION
Only operate the monocular in dark environments; if it is necessary to operate the device in daylight,
use the objective lens cap to cover the objective lens.
NOTE :
When using the monocular without a mounting device, make sure to place the neck cord
around your neck.
(1) Ensure that the battery are installed per paragraph 3.3.2.
(2) Turn the power switch to ON.
NOTE :
The sharpest image will be observed only when the objective lens and eyepiece lens are prop-
erly focused.
(3) Rotate the diopter adjustment for the clearest view of the image intensifier screen.
(4) Focus the objective lens while observing an object until the sharpest image is obtained.
3.4.2. HEAD MOUNTED OPERATION
Perform the following procedures for head mounted operation.
CAUTION :
Only operate the monocular in dark environments; if it is necessary to operate the device in
daylight, use the objective lens cap to cover the objective lens.
(1) Verify that the batteries are installed per paragraph 3.3.2.
(2) Put the headmount on per the instructions in paragraph 3.3.6.
NOTE :
Before attaching the monocular, depress the eye relief adjustment and slide the headmount
socket all the way forward; this will make it easier to align the monocular, eyecup, and eyepiece
lens to the eye.
(3) Align the headmount/ helmet mount adapter’s latch to the headmount socket (Figure 3-19). Hold
the latch lever down while installing the monocular into the headmount socket.
