29
3.3 ASSEMBLY AND PREPARATION FOR USE
3.3.1. UNPACKING
The following steps must be taken prior to each mission in which the MUNVM is used.
CAUTION :
Relieve air pressure from inside the shipping and storage case by compressing opposite sides
of the case before releasing the latches.
(1) Release the latch securing the top of the shipping and storage case and open it.
(2) Verify that all items were shipped (see Figure 2-1).
(3) Open the carrying case (Figure 2-3), remove MUNVM, and inventory the items.
(4) Inspect the monocular for obvious evidence of damage to optical surfaces, body, eyecup, eyeguard,
power switch, battery cap, etc. Ensure that all optical surfaces are clean and ready for use. If necessary,
clean with dry lens paper.
3.3.2. INSTALLATION OF THE BATTERY
CAUTION :
To protect the image intensifier, keep the objective lens cap securely fitted over the lens when
the monocular is not in use or when it is being operated in daylight conditions.
The MUNVM operates with one AA battery. The battery is not supplied with the MUNVM and must be
obtained separately.
At operating temperatures below -20°C (-4°F), Alkaline batteries are not recommended, as the battery
life will be severely reduced. Lithium-iron disulfide L91 1.5V AA batteries should be used in conditions
below -20°C (-4°F).
TABLE 3-2. ESTIMATED BATTERY LIFE
BATTERY TYPE TEMPERATURE NEGLIGIBLE
IR SOURCE USAGE
IR SOURCE
USAGE 10% OF THE TIME
AA Alkaline 21°C (70°F) 60 Hrs 55 Hrs
AA Lithium L91 21°C (70°F) 70 Hrs 65 Hrs
AA Alkaline -20°C (-4°F) 12 Hrs 10 Hrs
AA Lithium L91 -20°C (-4°F) 60 Hrs 55 Hrs
CAUTION :
Verify that the device is OFF before installing the battery.
Install the AA battery into PVS14 or 6015 as follows.
(1) Unscrew the battery cap.
(2) Align the polarity markings on the battery with those etched onto the battery compartment.
(3) Replace the battery cap and tighten it.
