Image Tube Gen 3 Ghost - “Ghost“ White Phosphor 47-57 lp/mm
Magnification 3x 5x 8x
Lens System F1:1.65, 80 mm F1:1.5, 108 mm F1:2,0, 160 mm
FOV 12.5° 9.5° 6.5°
Range of Focus 5 m to infinity 10 m to infinity 15 m to infinity
Exit pupil size 14 mm
Diopter Range +5 to - 5
Infrared Illuminator Detachable Long Range Illuminator
Low Battery Indicator Yes (in FOV)
Power Supply
CR123 Lithium 3V (1) or CR123 type rechargeable batteries
with voltage 3.7V (1)
Battery Life Up to 50 hours
Environmental Rating Water and fog resistant
Operating Temperature -51°C to +49°C
Dimensions (mm) 265 x 140 x 63 305 x 140 x 86 350 x 140 x 100
Weight (kg) 1.0 1.3 1.5
Night Vision Bi-Ocular
DISCOVERY
Ghost
The Armasight Discovery is the ultimate long-range night vision observation
device.
Providing enhanced performance and a highly ergonomic body, the Discovery
enables users to view long distances comfortably for extended periods of time. The
Discovery is the perfect tool for perimeter security, observing nature, and performing
long-range surveillance.
The Armasight Discovery Ghost is equipped with high-performance white phosphor
Cen3 IIT which provide users with natural B&W night vision displays, clearer details,
better contrast, and more distinct shapes and shadows.
Equipped with brand new, high-performance image intensifier tubes, our Discovery
Binoculars can be hand-held or mounted onto a tripod.
Available in 3X, 5X or 8X models, the Discovery is fitted with an detachable long-
range IR illuminator and advanced electronic protection circuits. With a rugged
body that is both water and shock resistant, but still lightweight, the Armasight
Discovery is the ideal choice for hunting, wildlife observation, law enforcement, and
defense applications.
Rugged, light weight, and versatile design
3X, 5X, or 8X magnification
Fast, multi-coated, all-glass optics
Dual eye viewing system for comfortable long night time viewing
sessions
Detachable long-range infrared illuminator
Water and fog resistance
Tripod-mountable
Hand straps and neck strap for comfortable of use
Limited two-year warranty
