30
NOTE:
Remember that the center of impact on the target shifts in the opposite direction from
the direction that the reticle shifts. To bring the center of impact to the right/left and up/
down, you must shift the reticle to the left/right and down/up, respectively.
Up
DoWn
LeFT
BoreSIgHT ADjUSTMenT
rIgHT
FIGURE 3-17. BORESIGHT ADjUSTMENT BUTTONS
While holding down the central boresight adjustment button, push the up/down and right/left but-
tons (as in the figure) the necessary number of times to shift the reticle in the display. To control the
shifting of the reticle, check the running coordinate of the reticle center that is printed in the lower
left-hand corner of the display.
NOTE:
For display coordinates, the origin is the center of the display. The running coordinate of the ret-
icle is the number of incremental shifts of the reticle from the center of the display. The minus
(-) sign appears before the displayed number when the reticle shifts left or down (the center of
impact on the target shifts right or up, respectively).
To reset to zero azimuth and elevation, push the combination of buttons (Up+Down). The reticle will
shift in the display center. The ZERO indication will appear in the display.
10. Fire a series of shots to check the boresight.
11. After completing, save your boresight settings by pushing the “save” combination of buttons
(Right+Left). The SAVE indication will appear in the display.
12. After completing the boresight adjustment procedure, turn off the Drone PRO and place the cap
over the objective lens.
3.3.3 OPERATING AN IR ILLUMINATOR
Use an IR illuminator when there is little to no ambient light.
CAUTION:
IR illuminator infrared light will be invisible to the naked eye. However, the light can be de-
tected by other night vision devices.
