14
TABLE 2-5. OPTICAL DATA
ITEM DRONE PRO 5X DRONE PRO 5X-10X
Magnification 5x
(10x with optional Afocal
Doubler)
10x
(5x without included Afocal
Doubler)
Field of View - ang. X degrees 5.7° 3.2°
- ang. Y degrees 4.2° 2.3°
Objective Focal Length 50mm 90mm
Objective F-number 1:1.2 1:1.4
Eyepiece Focal Length 25 mm
Entrance Pupil Diameter 42mm 65mm
Exit Pupil Diameter 10 mm
Eye Relief 45 mm
Focus Method Manual
Focusing Range 10m to infinity 10m to infinity
Diopter Adjustment Manual
Diopter Adjustment Range ±5 diopter
TABLE 2-6. ENVIRONMENTAL DATA
ITEM DATA
Operating Temperature -40 to +50°C (-40 to +122°F)
Storage Temperature -50 to +70°C (-58 to +158°F)
Recoil Resistance 700g
Immersion 10m for 30 min
TABLE 2-7. IR ILLUMINATOR DATA
ITEM IR810 IR810W (OPTIONAL) IR850W (OPTIONAL)
IR Emitter Type LED LED LED
Power 320 mW 320 mW 500 mW
Peak Wavelength 810 nm 810 nm 850 nm
Illumination Range Up to 300 m Up to 500 m Up to 800 m
Divergence 8 to 12° 2 to 30° 2 to 30°
Battery Single CR123А (3V)* Single CR123А (3V)* Single CR123А (3V)*
Battery Life
at 20 °C (68 °F) From 1.5 hr (Full Power)
to 10 hr (1/4 Power) From 1.5 hr (Full Power)
to 10 hr (1/4 Power) From 1.5 hr (Full Power)
to 10 hr (1/4 Power)
Overall Dimensions
(with Mount) 117Ч41Ч37 mm
(4.6”Ч1.6”Ч1.5”) 120Ч42Ч38 mm
(4.7”Ч1.6”Ч1.5”) 120Ч42Ч38 mm
(4.7”Ч1.6”Ч1.5”)
Weight (with Mount,
without Battery) 102 g
(3.6 oz) 102 g
(3.6 oz) 102 g
(3.6 oz)
Operating Temperature -30 to +50°С
(-22 to 122°F)
-30 to +50°С
(-22 to 122°F) -30 to +50°С
(-22 to 122°F)
Storage Temperature -50 to +70°С
(-58 to 158°F) -50 to +70°С
(-58 to 158°F) -50 to +70°С
(-58 to 158°F)
Environmental Rating Water Resistant Water Resistant Water Resistant
* Any CR123 type rechargeable batteries with voltage 3.2V can be used
