13
2.2 DRONE PRO SPECIFICATIONS
TABLE 2-2. SYSTEM DATA
ITEM DRONE PRO 5X DRONE PRO 5X-10X
CCD Camera High-rate Near-IR Hypersensitive High Resolution CCD Camera
Pixel CCD Array Format 752×582
CCD Array Spectral Response 0.4 to 1.1 µm
Resolution, mrad 30 SOA 16SOA
Display Type AMOLED SVGA 060
Pixel Display Format 752×582
Display Brightness Discretely Adjustable to 8 Levels
Turn-on Time, max 3 sec
Reticle Type 7-Pattern Digitally Controlled: “Dot”/ “Small Crosshair”/ “Big Crosshair”/
“Crosshair with Dot”/ “Circle”/ “Circle with Dot”/ “No Reticle”
Reticle Color Black / White
Windage/Elevation Boresight
Adjustment Type
Digitally Controlled
Windage/Elevation
Boresight Increment* 60 SOA
0.3 mils
3cm/100m
33 SOA
0.16 mils
1.6cm/100m
Boresight Adjustment Range ±2° ±1°
Analog Input Format PAL/ NTSC
Analog Output Format PAL
PAL Output Resolution 768×574 pixels
* The use of the Afocal Doubler changes the boresight increment value.
TABLE 2-3. MECHANICAL DATA
ITEM DRONE PRO 5X DRONE PRO 5X-10X
Weapon Mount Type Picatinny, MIL STD 1913, or Weaver Rails
Overall Dimensions 270Ч67Ч80mm (10.6”Ч2.6”Ч3.2“) 360Ч85Ч85mm (14.2”Ч3.3”Ч3.3“)
Height of the Drone PRO Axis
above Picatinny/Weaver Rail
40 mm (1.57 in)
Weight (w/o Batteries) 0.75 kg (1.6 lbs) 0.95 kg (2.1 lbs)
TABLE 2-4. ELECTRICAL DATA
ITEM DATA
Battery Two CR 123A (2×3V)
Current Consumption, maximum 500 mA
Battery Life at 20 °C (68 °F) 3 hr
External Power Supply 6 VDC/ 1 А
