13
2.2 SPECIFICATIONS
TABLE 2-2. SYSTEM DATA
ITEM DATA
Magnification Unity (1X)
Boresight Characteristics:
— Accuracy
— Retention
— Repeatability Factory aligned to 2 MOA or better
Permanent to within 4 MOA or better
Within 2 MOA
System Resolution subject to Tube Resolution:
— 45 to 54 lp/mm
— 55 to 64 lp/mm
— Over 65 lp/mm 0.65 mrad/lp
0.53 mrad/lp
0.45 mrad/lp
TABLE 2-3. MECHANICAL DATA
ITEM DATA
Dimensions (L×W×H) 125Ч68Ч55mm (4.9x2.7x2.2 in)
Weight* (without Mount) 0.43 kg (0.95 lbs)
Weight* (with Mount, Light Suppressor) 0.48 kg (1.06 lbs)
Height of the CO-MINI Axis above Picatinny/Weaver Rail
(with/without Raiser) 38.8/29.3mm (1.53/1.15 in)
* — Without Battery
TABLE 2-4. ELECTRICAL DATA
ITEM DATA
Battery AA (1.5V) CR123A (3V)
Cell Life at 20°C 25 hr 45 hr
Interrupting Time* 60 minutes
* Optional feature. Interrupting Time setting can be changed at the production stage, or the function can be completely disabled.
TABLE 2-5. OPTICAL DATA
ITEM DATA
Objective Lens Focal Length 38mm
Objective Lens F/number 1:1.26
Focus Distance 20m to Infinity
Field of View 22°
Entrance Pupil Diameter 30.1mm
Exit Pupil Diameter 27.5mm
TABLE 2-6. ENVIRONMENTAL DATA
ITEM DATA
Operating Temperature -40 to +50°С (-40 to 122°F)
Storage Temperature -50 to +50°С (-58 to 122°F)
Illumination Required Natural night illumination
(overcast starlight to moonlight)
Immersion 10m for 30 minutes
MIL-STD-810 Complies
