6
GigaX2008EX L2 Managed Switch User Manual
3 Quick start guide
This section provides the basic instructions to set up the GigaX2008EX working
environment. Refer also to the GigaX2008EX Installation Guide.
Part 1 shows you how to install the GigaX2008EX on a flat surface or on a rack.
Part 2 provides instructions to set up the hardware.
Part 3 shows you how to configure basic settings on the GigaX2008EX.
Obtain the following information from your network administrator before
proceeding:
IP address for the switch
Default gateway for the network
Network mask for this network
3.1 Part 1 — Install the hardware
Connect the device to the power outlet, and your computer or network.
3.1.1 Install the switch on a flat surface
The switch should be installed on a level surface that can support the weight
of the switches and their accessories. Attach four rubber pads on the marked
location on the bottom of the switch.
3.1.2 Mount the switch on a rack
1. Attach brackets to each side of the switch and make the posts insert to the
switch.
2. Insert and tighten two screws to securely attach the bracket to the rack on
each side.
3.2 Part 2 — Set up the switch
Connect the device to the power outlet, and your computer or network.
3.2.1 Connect the console port
For console management, use an RS232 (DB9) to connect the switch. If you
want to use Web interface, connect your PC to the switch using the Ethernet
cable.
