11.2.1 Descriptors virtual digital output
The parameter 5EFDh is used to configure the virtual
output; it can be written/read through each
single element or as a whole object (by setting the subindex to 0).
OBJECT ATTRIBUTE I VALUE I MEANING
Index 5EFDh
Object code 08
virtual digital output configuration
Array
Number of the elements 16 16 Channels virtual digital output
06 Unsigned 16
Password
Access group
00 Non-existing
00 Non-existing
Access rights Read-All,
Write-All
Local address
I
x x x x
I
Manufacterer Specific
The parameter 5EFFh is used to read the
virtual digital output previously configured; the
status of the single Bits corresponds to the status of the virtual
digital output assigned to the
Bit during the configuration:
OBJECTATTRIBUTE
Index
VALUE
5EFFh
MEANING
Value (current status)
virtual digital output
Object code 07
I
Single variable
Index of the type of datum 05 The status of the single Bit
corresponds to the status of the
virtual digital output assigned
Length
Password
Access group
Access rights
Local address
02 2 Byte
00 Non-existing
00 Non-existing
I
01
1 Read-All
x x x x Manufacterer Specific
