6.1.2 PDC Output data Descriptor
This communication object has the information which determines the assignment of the drive parameters to
the
data
of the Process Data Channel outcoming from the Master. With the writing of this object the data
transfer of the data outcoming from the Master is automatically interrupted. In the case there is a conflict
between the index and the subindex, the assignment is not carried out and an error message is generated.
Moreover, the writing of this object causes the clearing of the corresponding Bit in the object output
Description of the object Output data descriptor>>:
OBJECT ATTRIBUTE VALUE MEANING
I
6001 h
I
PDC Output data descriptor
Object code
Index of the data Type
09 Record
20 Structure PDB
Password
I I
Non-existing
Gruppo d’accesso 00
Access rights 03 Read-All,
Write-All
Local Address x x x x Specific
Range of the descriptor values:
Subidex 1 : Unsigned8
Subindex 2 : Unsigned1 6
Subindex 3 : Unsigned8
Subindex 4 : Unsigned1 6
Subindex 5 : Unsigned8
Subindex n : Unsigned16
Subindex n + : Unsigned8
For further information refer to the Manual Profile 21 Drivecorn.
