GEI-100445
This is an example of the assignment of the drive parameters to the object output data Descriptor
and to the object input data Descriptor in the case of card with 16 Bit parameters.
Drive Parameter A Type of datum: Unsigned1 6
Not used
Drive Parameter B
Type of datum: Unsigned16
Not used
Object subindex Meaning of the object element Byte number of the
input data Descriptor>> Process Data Channel
Length of the Process Data Channel
2 Index of the Drive parameter A 1
(16 Bit)
3 Subindex of the Drive
parameter A
1
4 Not used.
Index 0000
2
5 Not used.
Subindex = 00
2
6 Index of the Drive Parameter B
(16 Bit)
3
7 Subindex of the Drive
Parameter B
3
8 Not used.
Index = 0000
4
9 Not used.
Subindex = 00
4
