Page 19
S
This is an example of the assignment of the drive parameters to the object
output data
and to the object
input data
with a32 Bit parameter.
Parameter A
Data Type: Unsigned32
Not used.
Not used.
Not used.
Object
subindex
Meaning of the object element
Byte number of the
input data
Process
Data
Channel
1
Length of the Process Data Channel
2
Index of the drive parameter A
1
32 Bit
3
4
Subindex of the drive parameter A
Not used.
Index = 0000
1
2
5
Not used.
Subindex = 00
2
6
Not used.
Index 0000
3
7
Not used.
Subindex = 00
3
8
Not used.
Index = 0000
4
9
Not used.
Subindex = 00
4
If the assignment of a drive parameter to the Process Channel is replaced with the assignment of a larger
parameter, the following Bytes of the object
Data Channel Descriptors, involved in the operation
must be cleared. If the assignment can not be correctly carried out , the response is negative.
IMPORTANT
In the current versions ot the
cards there is no control on the validity of the assignment of the
drive parameters to the Process Data Channel; the user, therefore, must control with care such assignment,
for example, the overlap of parameters or the overflow of the Process Data Channel capacities. In
the case these assignments are not carried out in a proper way, the system could behave in an unexpected
and potentially dangerous way.
