Secondary DC Power Distribution Bay H569-445
Issue 3 June 2012 5
Specifications
Output Voltage: -48Volts DC
Output Capacity: 800A per Distribution Panel
6 Load BDFB: 2400A per Side, 4800A Maximum per Bay
4 Load BDFB: 1600A per Side, 3200A Maximum per Bay
2 Load BDFB: 800A per Side, 1600A Maximum per Bay
Agency Approval: UL Listed (cULus), NEBs
Environment: 0C to +40C (+32F to +104F)
Cabinet:
Seismic Zone 4 Box Framework
Color: Central Office Soft Blue
Width: 26 inches (660mm) or 34 inches (864mm)
Height: 84 inches (2134mm)
Depth: 15 inches (381mm)
Weight: Approx. 375 pounds (6 panels)
Access: Front Fuse/Breaker and Alarm Access, Rear Wiring Access
Distribution: 28-Position Panel for Bullet-Style Protectors
Protectors:
• Bullet-Style Fuse Holders, TPS or TLS Fuses through 125A
• Single Pole LEL Bullet-Style Circuit Breakers through 100A
• Two-Pole LEL Bullet-Style Circuit Breakers through 150A
• Three-Pole LEL Bullet-Style Circuit Breakers through 250A
• No Protector Spacing Restrictions
• Maximum Loading
• 64% of protector rating - Continuous (List 1)
• 80% of protector rating - Maximum Load (List 2 - typically end of
discharge)
Accessories: External Ground Bar Assembly
Seismic Anchor Kits
Bullet-Style Fuse Holders, Fuses
Bullet-Style Circuit Breakers
2 ft Extension Cabinet for 9-ft application
4-1/2 ft Extension Cabinet for 11-1/2 ft applications
Top Cover for Bottom Feed Applications.
