Galaxy Power System GPS2436
Issue 1 August 2012 72
Compensation Feature. Move the cursor to
the field and use the <+> or <-> key to Enable
or Disable. Press to save the
change.
High Temp
Comp
This feature allows the system to
compensate for high temperatures.
Volt Step
Down
Battery step temperature can be set from
113-185F. At this temperature, the system
voltage is reduced by 0.17 X # of cells/string.
High Comp
Limit
This sets the maximum temperature for
which thermal compensation is active.
Decrease This sets the slope (mV/degC) for high
temperature compensation.
Nominal
Temp
This field set the temperature at which no
compensation is required. The system
voltage is at the setpoint float mode.
Low Temp Comp This feature allows the system to
compensate for low temperatures.
Low T Comp This enables or disables the low temperature
compensation feature.
Low Comp
Limit
This sets the minimum temperature for
which thermal compensation is active.
Increase This sets the slope (mV/degC) for low
temperature compensation.
8. Recharge Current
Limit
This feature sets the total amount of current
that will be allowed to recharge the batteries.
Limit The configuration of this field enables or
disables the feature.
Limit to This programmable value sets the maximum
amount of recharge current (in Amps) that
will be allowed for recharging the batteries.
The range is from 10 – 1000A.
9. Contactors Up to three optional LVD devices can be
connected to a Millennium and configured
from this screen.
