Galaxy Power System GPS2436
Issue 1 August 2012
45
Local Port
Software
EasyView software is a Windows-compatible communications package designed specifically for
use with Galaxy controllers. Download EasyView software from http://www.lineagepower.com
Wiring Alarm Outputs
These external alarms may be wired to customer external office alarms at their
destination.
Form-C Alarm Contact Ratings
60Vdc, 0.3A
Conductor Size for terminating on Alarm
board
18 – 22AWG (if less than 18AWG, use
multi-conductor cable for mechanical
integrity)
Refer to Table 9-B and 9-C for lead designations and their descriptions for leads
terminating on the BSL alarm interface board.
Table 9-B: Controller Alarm Descriptions and Pin Numbers
Pin
Number
Signal Name
Pin
Number
Signal Name
Pin
Number
Signal Name
1
PCRAO
33
MJFR
65
FAN
2
PCRAC
34
MNFR
66
AMN
3
PCRAR
35
MNFC
67
TFLT
4
PCRVR
36
MNFO
68
TBST
5
PCRVC
37
BDO
69
TRTN
6
PCRVO
38
BDC
70
PBTR
7
PCREO
39
BDR
71
PBT
8
PCREC
40
ACFR
72
OS
9
PCRER
41
ACFC
73
TR1
10
PMJAR
42
ACFO
74
TEQ
11
PMJAC
43
RFAO
75
ETR
12
PMJAO
44
RFAC
76
ETRR
13
PMJEO
45
RFAR
77
RO
14
PMJEC
46
HVR
78
ROR
15
PMJER
47
HVC
79
TR2
16
PMJVR
48
HVO
80
TR4
17
PMJVC
49
UR1O
81
RBRPO
