Galaxy Power System GPS2436
Issue 1 August 2012 44
8. After approximately 1 minute, the green LED on the front of the module will
blink once approximately every 5 seconds. Detailed troubleshooting
information may be found in the User’s Guide for Millennium II Controller
Advanced Features manual.
Thermal Probes
Without thermal probes, many of the controller’s battery management features will not
function, or produce erroneous results. Some features requiring thermal inputs are:
• Slope Thermal Compensation
• Reserve Time Prediction
• High Temperature Alarm
• Ambient High and Low Temperature Alarms
• High Temperature Disconnect
Step Action
NOTE: The controller supports a number of thermal probe inputs. The type of
probe used determines where it is connected on the controller. Detailed
thermal probe and battery management information may be found in the
User’s Guide for Millennium II Controller Advanced Features manual.
1. The following table shows the type of probe and connector location on the
Millennium:
Type of Probe Comcode Controller Connection
Location
10/30K P3
210E Thermal Probe
Mux
P3
1 Wire Temperature
Monitoring Devices
P7
Terminal Block
Interface for 3
additional 10k probes
or 210E connection
TB2
Pin Description
1 Probe 2
2 Probe 2 RTN
3 Probe 3
4 Probe 3 RTN
5 Probe 4
6 Probe 4 RTN
USB Interface
This interface is reserved for future use.
