GE Industrial Solutions GPS2436 User Manual
User’s guide

GPS2436
(H5692436)
User’s Guide
GPS2436 is available with Galaxy Millennium II or Galaxy Pulsar Plus controllers.
This manual is based on and includes information specific to the Galaxy Millennium II controller.
Refer to these documents for information specific to the Galaxy Pulsar Plus controller
• Galaxy Pulsar Plus Product Manual CC848815341
• GPS2436 Ordering Guide H5692436.
Product Manual
Comcode
850022020
Issue 1
August 2012
Table of contents
Document Outline
- 1 Introduction
- 2 System Description
- 3 Galaxy Millennium II Controller
- 4 Rectifiers
- 5 AC Input Panels
- 6 Battery Connection Panels
- 7 DC Distribution Panels
- 8 External Return Bars
- 9 Millennium II Controller Operation
- 10 Acceptance Testing
- 11 Circuit Boards
- 12 Specifications
- 13 Safety
- 14 Maintenance and Replacement
- 15 Troubleshooting Procedure
- 16 Product Warranty
