CPS3200U Upstream System – 23” Product Manual CPS3200U
CC848779826 r09 December 2013 9
3 Ordering
Ordering Codes
This is a short list of CPS3200 items that can be purchased. See Line Power Product Line Brochure for detail.
Table 2 Ordering Codes
CODE COMCODE DESCRIPTION
Items for new installation or growth of existing installations
QS912A 108996732 Converter Shelf with Alarm Module (provides landings for double-hole lugs)
QS982A 108996641 Converter Card (For first install on single shelf systems the sum of converters cards
and converter slot fillers should be 16. For example: 14 Converter cards and 2
Converter slot fillers)
CC109121992 Converter slot filler
QS930A 108996930 Fan Shelf with 2 redundant fan trays
QS941A 108996947 Controller with Display and Ethernet capabilities
CC848756577 Airflow baffle without bracket for air filter
CC109102638 Airflow baffle with bracket for air filter. Includes air filter.
Replacement air filter CC109121984 listed below.
Spares: Items for repair or maintenance of existing installation
CC109121984 Air filter to be used with Airflow baffle CC109102638 (Spare)
QS930B 108997623 Fan tray assembly (Spare)
QS920A CC109102118 Alarm Module (Spare)
Expansion Items: Provide a 4 ft long wireset to transmit alarm signals past a baffle.
Use when adding a second fan shelf to an existing system.
H5694820G050 CC109122074 Fan Shelf w/2 fan trays, wireset, baffle, filter, controller cover
H5694820G051 CC109132271 Fan Shelf w/2 fan trays, wireset, baffle, controller cover
H5694820G012 CC109122082 Converter Shelf, RJ45 wireset, hardware, alarm board (same as QS912A above)
Note: A baffle must be placed above the topmost converter shelf for use in customer premise locations for UL safety
compliance. Baffles are not required in restricted access locations such as outside plant cabinet, CEV or hut locations.
The baffle can be ordered separately from the above list or in combination with a fan shelf by choosing an item from
this list.
Lugs
GA Description
WP-91412
List Comcode Burndy Equivalent
Similar Lugs
NOTE: May have different dimensions.
Panduit T&B
2 Straight, STR 54 405348202 YA2CL-2TC14 LCD2-14A-Q 54207 (STR)
2 Straight, FLEX 8 405347683 YAV2C-L2TC14-FX LCDX2-14A-E 54208 (Flex)
2 45°, STR - - YA2CL-2TC14-45 LCD2-14AH-Q 54207UF (STR)
2 45°, FLEX 193 408210524 YAV2C-L2TC14-FX-45 LCDX2-14AH-E 54208UF (Flex)
4 Straight, STR / FLEX 5 405347576 YAV4C-L2TC14-FX LCDX4-14A-L (FLEX)
LCD4-14A-L (STR) 54206 (STR)
54206 (FLEX)
4 45°, STR / FLEX - - YAV4C-L2TC14-FX-45 LCDX4-14AH-L (FLEX)
LCD4-14AH-L (STR) 54206UF (STR)
54206UF (FLEX)
6 Straight, STR / FLEX 3 405347519 YAV6C-L2TC14-FX LCDX6-14A-L (FLEX)
LCD6-14A-L (STR) 54205 (STR)
54205 (FLEX)
6 45°, STR / FLEX - - YAV6C-L2TC14-FX-45 LCDX6-14AH-L (FLEX)
LCD6-14AH-L (STR) 54205UF (STR)
54205UF (FLEX)
8 Straight, STR / FLEX 75 406021626 YA8CL2TC14 LCDX8-14A-L (FLEX)
LCD8-14A-L (STR) 542040410 (STR)
542040410 (FLEX)
8 45°, STR / FLEX - - YA8CL2TC14-45 LCDX8-14AH-L (FLEX)
LCD8-14AH-L (STR) N/A
