System Test Kit 50
Circuit Breaker Settings in report for Protection Test
Test Results
Trip Time Information Displays all the Trip time Information.
Pre-Fault Time Time for which the Pre-Fault signals are injected.
Expected Trip time Expected trip time for the test.
Post-Fault Time Time for which the Post-Fault signals are injected.
Observed Trip time Observed Trip time for the test.
Digital Input Time Stamping Time Stamping for Digital inputs.
Comments Comments that are entered by the user while generating reports.
Prepared by This is an empty field given for the operator to manually sign after report
generation.
Date Date is the report generated date.
Table 1-19 Circuit Breaker settings in report for Protection Test
LT Protection Test
Pickup setting Long time pickup setting.
Delay setting Delay band setting.
Short Time Protection Test
Status ST Protection enabled or disabled condition.
Pickup Setting Pickup setting of Short time protection.
I2T Status Inverse trip time enabled status.
Delay setting Delay setting of Short time protection.
Ground fault
Status GF Protection Enabled or Disabled condition.
Pickup Setting Pickup setting of Short time protection.
I2T Status Inverse trip time enabled status.
Delay setting Delay setting of Short time protection.
IOC Protection Test
Status Enabled or Disabled status of the IOC Protection.
Pickup Setting Pickup setting of IOC.
Table 1-18 Fields available in the test reports
