System Test Kit 42
* Entellisys Version 3.0 systems
** Entellisys Version 4.0 systems
Table 1-14 Default values for user-defined relay protection tests
User-Defined Frequency / Multiplier / KW Range
Prefault Fault Post Fault
Over Frequency 50 Hz – 60 Hz
0.1 Hz increment 50 Hz – 70 Hz
0.1 Hz increment 50 Hz – 60 Hz
0.1 Hz increment
Under Frequency 50 Hz – 60 Hz
0.1 Hz increment 44 Hz – 60 Hz
0.1 Hz increment 50 Hz – 60 Hz
0.1 Hz increment
Overvoltage 96% to 104%
0.5% increment 104% to 132%
0.5% increment 96% to 104%
0.5% increment
Undervoltage 96% to 104%
0.5% increment 47.5% to 95%*
8.5% to 95%**
0.5% increment 96% to 104%
0.5% increment
Phase Loss 0% to 7%
1% increment 7% to 51%
1% increment 0% to 7%
1% increment
Power Reversal 0 to 100 KW
10 KW increment 0 to 1000 KW
10 KW increment 0 to 100 KW
10 KW increment
High Current 0% to 100%
5% increment 45% to 205%
5% increment 0% to 100%
5% increment
