Electrical specifications (continued) – GE Industrial Solutions EQW010-040 Series (Eighth-Brick) User Manual
Page 3
Data Sheet
October 5, 2013
EQW010-040 Series Power Modules
36 – 75Vdc Input; 1.0 to 12.0Vdc Output; 10 to 40A Output Current
LINEAGE
POWER
3
Electrical Specifications
(continued)
Parameter
Device
Symbol
Min
Typ
Max
Unit
Nominal Output Voltage Set-point
B
V
O, set
11.76 12.0 12.24 V
dc
V
IN
=V
IN, min
, I
O
=I
O, max
, T
A
=25°C) A
V
O, set
4.90 5.0 5.10 V
dc
F
V
O, set
3.23 3.3 3.37 V
dc
G
V
O, set
2.45 2.5 2.55 V
dc
Y
V
O, set
1.76 1.8 1.84 V
dc
M
V
O, set
1.47 1.5 1.53 V
dc
P
V
O, set
1.18 1.2 1.22 V
dc
S1R0
V
O, set
0.98 1.0 1.02 V
dc
Output Voltage
All
V
O
-3.0
+3.0 %
V
O, set
(Over all operating input voltage, resistive load,
and temperature conditions until end of life)
Output Regulation
Line (V
IN
=V
IN, min
to V
IN, max
)
B, A, F, G
0.2 %
V
O, set
Y,
M,
P,
S1R0
5
mV
Load (I
O
=I
O, min
to I
O, max
)
B, A, F, G
0.2
%
V
O, set
Y,
M,
P,
S1R0
5
mV
Temperature (T
ref
=T
A, min
to T
A, max
) All
1.0 %
V
O, set
Output Ripple and Noise on nominal output
(V
IN
=V
IN, nom
,I
O
= I
O, max
, T
A
=T
A, min
to T
A, max
)
RMS (5Hz to 20MHz bandwidth)
B
30 mV
rms
Peak-to-Peak (5Hz to 20MHz bandwidth)
B
100 mV
pk-pk
RMS (5Hz to 20MHz bandwidth)
All, except B
25 mV
rms
Peak-to-Peak (5Hz to 20MHz bandwidth)
All, except B
75 mV
pk-pk
External Capacitance
B
C
O, max
0
1,500
μF
A
C
O, max
0
10,000
μF
F, G, Y, M, P,
S1R0
C
O, max
0*
20,000
μF
Output Current
B
I
o
0
10 A
dc
A
I
o
0
20 A
dc
F
I
o
0
30 A
dc
G
I
o
0
35 A
dc
Y,
M,
P,
S1R0
I
o
0
40 A
dc
Output Current Limit Inception (Hiccup Mode )
All, except G
I
O, lim
105 115 130 % I
o
(V
O
= 90% of V
O, set
) G
I
O, lim
103 115 130 % I
o
Output Short-Circuit Current
All I
O, s/c
130 150 A
rms
(V
O
≤250mV) ( Hiccup Mode )
Efficiency B
η
93.0
%
V
IN
= V
IN, nom
, T
A
=25°C A
η
91.7
%
I
O
=I
O, max ,
V
O
= V
O,set
F
η
92.0
%
G
η
89.8
%
Y
η
88.3
%
M
η
87.1
%
P
η
85.0
%
S1R0
η
83.2
%
Switching Frequency
All
f
sw
420 kHz
* Note: For 1.0V
O
(S1R0) and 1.2 V
O
(P) device codes, external capacitance, C
O
, should be 1000uF minimum to achieve monotonic start-up with
very light load (≤ 2Amp).
