GE Industrial Solutions EQW010-040 Series (Eighth-Brick) User Manual

Page 28

Data Sheet

October 5, 2013

EQW010-040 Series Power Modules

36 – 75Vdc Input; 1.0 to 12.0Vdc Output; 10 to 40A Output Current

Document No: DS06-112 ver. 1.27

PDF name: EQW010-040 Series.pdf

World Wide Headquarters
Lineage Power Corporation
601 Shiloh Road, Plano, TX 75074, USA
+1-800-526-7819

(Outside U.S.A.: +1-972-244-9428)
www.lineagepower.com
e-mail: [email protected]

Asia-Pacific Headquarters
Tel: +65 6593 7211

Europe, Middle-East and Africa Headquarters
Tel: +49 89 878067-280

India Headquarters
Tel: +91 80 28411633

Lineage Power reserves the right to make changes to the product(s) or information contained herein without notice. No liability is assumed as a result of their use or

application. No rights under any patent accompany the sale of any such product(s) or information.

Lineage Power DC-DC products are protected under various patents. Information on these patents is available at

www.lineagepower.com/patents

Table 2. Device Options

Note: Legacy device codes may contain a –B option suffix to indicate 100% factory Hi-Pot tested to the isolation voltage specified in
the Absolute Maximum Ratings table. The 100% Hi-Pot test is now applied to all device codes, with or without the –B option suffix.
Existing comcodes for devices with the –B suffix are still valid; however, no new comcodes for devices containing the –B suffix will
be created.

Option*

Suffix**

Negative remote on/off logic

Auto Re-start (for Over Current / Over voltage Protection)

Pin Length: 3.68 mm ± 0.25mm , (0.145 in. ± 0.010 in.)

Pin Length: 2.79 mm ± 0.25mm , (0.110 in. ± 0.010 in.)

Heat plate (Module height = 12.2 mm (0.48 in.) nominal, use with cold-plates

-C

Heat plate (Module height = 10.4 mm (0.41 in.) nominal, use with heat sinks

-H

Surface mount connections (not available with heat plate options -C, -H)

-S

Alternative Voltage Programming equations (1.0V and 1.2V modules only)

-V
