Data Sheet
October 5, 2013
EQW010-040 Series Power Modules
36 – 75Vdc Input; 1.0 to 12.0Vdc Output; 10 to 40A Output Current
LINEAGE POWER 27
Ordering Information
Please contact your Lineage Power Sales Representative for pricing, availability and optional features.
Table 1. Device Codes
Product Codes Input Voltage
Output
Voltage
Output
Current
On/Off
Logic
Connector
Type
Comcodes
EQW010A0B1 48V (36-75Vdc) 12V 10A Negative Through hole 108997284
EQW020A0A41-SB 48V (36-75Vdc) 5V 20A Negative Surface Mount CC109103966
EQW030A0F1 48V (36-75Vdc) 3.3V 30A Negative Through hole 108996096
EQW010A0BZ 48V (36-75Vdc) 12V 10A Positive Through hole CC109129152
EQW010A0B1Z 48V (36-75Vdc) 12V 10A Negative Through hole CC109114823
EQW010A0B641Z 48V (36-75Vdc) 12V 10A Negative Through hole CC109122116
EQW010A0B4-CZ 48V (36-75Vdc) 12V 10A Positive Through hole CC109146404
EQW010A0B41-CZ 48V (36-75Vdc) 12V 10A Negative Through hole CC109135043
EQW010A0B1-HZ 48V (36-75Vdc) 12V 10A Negative Through hole CC109122207
EQW010A0B1-SZ 48V (36-75Vdc) 12V 10A Negative Surface Mount CC109114641
EQW010A0B41-SZ 48V (36-75Vdc) 12V 10A Negative Surface Mount CC109127957
EQW020A0A1Z 48V (36-75Vdc) 5V 20A Negative Through hole CC109114402
EQW020A0A61Z 48V (36-75Vdc) 5V 20A Negative Through hole CC109132701
EQW020A0A641Z 48V (36-75Vdc) 5V 20A Negative Through hole CC109139052
EQW020A0A81Z 48V (36-75Vdc) 5V 20A Negative Through hole CC109151560
EQW020A0A61-CZ 48V (36-75Vdc) 5V 20A Negative Through hole CC109127817
EQW020A0A641-CZ 48V (36-75Vdc) 5V 20A Negative Through hole CC109149051
EQW020A0A1-HZ 48V (36-75Vdc) 5V 20A Negative Through hole CC109122198
EQW020A0A4-HZ 48V (36-75Vdc) 5V 20A Positive Through hole CC109140415
EQW020A0A41-HZ 48V (36-75Vdc) 5V 20A Negative Through hole CC109143517
EQW020A0A41-SZ 48V (36-75Vdc) 5V 20A Negative Surface Mount CC109113866
EQW020A0A41-SBZ 48V (36-75Vdc) 5V 20A Negative Surface Mount CC109114096
EQW030A0F1Z 48V (36-75Vdc) 3.3V 30A Negative Through hole CC109114063
EQW030A0F41Z 48V (36-75Vdc) 3.3V 30A Negative Through hole CC109121225
EQW030A0F61Z 48V (36-75Vdc) 3.3V 30A Negative Through hole CC109136132
EQW030A0F641Z 48V (36-75Vdc) 3.3V 30A Negative Through hole CC109138921
EQW030A0F841Z 48V (36-75Vdc) 3.3V 30A Negative Through hole CC109133402
EQW030A0F1-HZ 48V (36-75Vdc) 3.3V 30A Negative Through hole CC109122173
EQW030A0F41-HZ 48V (36-75Vdc) 3.3V 30A Negative Through hole CC109137353
EQW030A0F641-HZ 48V (36-75Vdc) 3.3V 30A Negative Through hole CC109141033
EQW030A0F41-SZ 48V (36-75Vdc) 3.3V 30A Negative Surface Mount CC109129158
EQW035A0GZ 48V (36-75Vdc) 2.5V 35A Positive Through hole CC109162335
EQW035A0G1Z 48V (36-75Vdc) 2.5V 35A Negative Through hole CC109114427
EQW035A0G641Z 48V (36-75Vdc) 2.5V 35A Negative Through hole CC109138938
EQW040A0Y1Z 48V (36-75Vdc) 1.8V 40A Negative Through hole CC109114451
EQW040A0Y641Z 48V (36-75Vdc) 1.8V 40A Negative Through hole CC109132180
EQW040A0Y41-SZ 48V (36-75Vdc) 1.8V 40A Negative Surface Mount CC109129202
EQW040A0M1Z 48V (36-75Vdc) 1.5V 40A Negative Through hole CC109114435
EQW040A0M61-CZ 48V (36-75Vdc) 1.5V 40A Negative Through hole CC109127593
EQW040A0P1Z 48V (36-75Vdc) 1.2V 40A Negative Through hole CC109114443
EQW040A0P641Z 48V (36-75Vdc) 1.2V 40A Negative Through hole CC109121258
EQW040A0P41-SZ 48V (36-75Vdc) 1.2V 40A Negative Surface Mount CC109127841
EQW040A0S1R01Z 48V (36-75Vdc) 1.0V 40A Negative Through hole CC109114492
EQW040A0S1R041-SZ 48V (36-75Vdc) 1.0V 40A Negative Surface Mount CC109125787
-Z Indicates RoHS Compliant modules
