2. Types and Ratings
2-2
2-2. UL Ratings
(1)
Current Max. HEAVY DUTY STANDARD DUTY Degree of Cat. No. Weight Cooled
rating starting 200V 230V 460V 200V 230V 460V protection
current
A A HP HP HP HP HP HP Kg. Lbs.
14 63 3 3 7.5 3 3 7.5 IP-00 QC2FDP 4.3 9.48 Natural
17 77 3 3 10 3 3 10 IP-00 QC2GDP 4.3 9.48 Natural
22 99 5 7.5 15 5 7.5 15 IP-00 QC2HDP 4.6 10.14 Natural
34 153 7.5 7.5 20 10 10 25 IP-00 QC2IDP 4.6 10.14 Natural
48 216 10 15 30 15 15 30 IP-00 QC2JDP 12.5 27.56 By fan
63 284 15 20 40 20 20 40 IP-00 QC2KDP 12.5 27.56 By fan
72 324 20 20 40 20 25 50 IP-00 QC2LDP 17.0 37.48 By fan
105 473 30 30 60 30 30 75 IP-00 QC2MDP 17.0 37.48 By fan
156 702 40 50 100 50 60 125 IP-00 QC2NDP 45.0 99.20 By fan
240 1080 60 75 150 75 75 200 IP-00 QC2QDP 45.0 99.20 By fan
315 1418 75 100 200 100 125 250 IP-00 QC2RDP 55.0 121.25 By fan
370 1665 100 125 250 125 150 300 IP-00 QC2SDP 55.0 121.25 By fan
500 2250 150 150 350 150 200 400 IP-00 QC2TDP 80.0 176.36 By fan
630 2835 200 200 400 200 250 500 IP-00 QC2UDP 105.0 231.47 By fan
850 3825 250 300 600 300 350 700 IP-00 QC2VDP 120.0 264.54 By fan
Notes: (1) = Ratings in Amps. given for ambient temperature up to 40
°
C and 1000m altitude.
Derate output current by 1.5% /
°
C above 40
°
C.
Derate output current by 1% / 100m above 1000m.
