4-3. Monitor block parameters
Function Display
Status
Motor current
Software version
Main source voltage (1)
Power factor
Line power
Elapsed time
Error trace buffer
Password
E2PROM writing
Parameter display
selection
4. Programming
O N
M x x x
v x x x
V x x x
P F x x
w x x x
E x x x
e x x x
K x x x
W x x x
G x x x
Description
Switch on time. Equipment is connected to main supply
Stop
Remote control through serial port
Kick start
Acceleration ramp
Full conduction / Override (full voltage)
Energy saving
Soft stop
Pump control
DC braking
Inching / slow speed
Linear ramp (tacho feedback needed)
Displays motor current in Amps.
Current higher than 999A is displayed in kA.
If parameter UFxx is not calibrated, the motor current is
displayed in % In
xxx = Version number.
Displays line voltage in Volts.
Displays line Power Factor.
Displays Line Power.
Displays RUN time in Hours (x 1000)
Saves the last four errors:
e0xx:
Fault 1 -Latest fault- xx: Fault code error
e1xx: Fault 2
e2xx: Fault 3
e3xx: Fault 4
= 69 allows E2PROM writing operation
= 10 Key lock enabled
= 20 Key lock disabled
Saves the unit current parameters to the E2PROM.
This rewrites the last values saved. (Password 69 required)
CAL: Displays Calibration Parameters
BAS: Displays Basic Parameters
ADV: Displays Advanced Parameters
ALL: Displays All parameters
4-4
Default Range Unit
ON
STOP
LOCK
PULS
RAMP
FULL
SAVE
SOFT
PUMP
DCBK
INCH
TACH
000-999
1.0-9.9
-
-
00-99
-
-
e0xx-e3xx
000-999
ON, OFF
CAL, BAS, ADV,
ALL
O N
K 0 0 0
W O F F
G B A S
-
-
-
-
-
-
-
-
-
-
-
-
A
kA
%
-
V
%
kW
Hrs
-
-
-
-
Note: (1) Monitors L1
