GE
Data Sheet
CP2000DC54-PE series dc-dc converter
Input: -40Vdc to -72Vdc; Outputs: ±54Vdc @ 2000W; 5Vdc @ 4W
August 20, 2013
©2013 General Electric Company. All rights reserved. Page 4
Mechanical, Environmental and EMC Specifications
Dimensions (nominal)
Length (in./mm) 13.85 / 351.8
Width (in./mm) 4.00 / 101.6
Height (in./mm) 1.66 / 42.2
Weight (lb/kg) 4.6 / 2.1
Environmental
Parameter Min Typ Max Units Notes
Ambient Temperature
Operating
Ambient Derating
Power Derating
2
-5 4
1
45
1
°C
°C
%/°C
Air inlet from sea level to 5,000 feet.
Per 1,000 feet above 5,000 feet.
Up to 55°C
Storage Temperature -40 85 °C
Humidity 5 95 % Relative humidity, non-condensing
Shock and Vibration
Operational Test
Test Levels
Drop and Tip Over
IEC 68-2
IEC 721-3-2
IEC 68-2-31
Earthquake Rating 4 Zone Per Telcordia GR-63-CORE, all floors, when installed in CP Shelf.
EMC, Performance
Parameter Min Typ Max Units Notes
Radiated Emissions 5 FCC and CISPR22 (EN55022) - Class A 3
Conducted Emissions - dc Telcordia GR-1089-CORE and CISPR22 (EN55022) - Class A
ESD Error free per EN/IEC 61000-4-2 Level 4 (8 kV contact discharge, 15 kV air discharge).
Radiated Immunity Error free per EN/IEC 61000-4-3 Level 3 (10 V/m).
Differential mode surge 100 Vdc ANSI T1.315, No errors
Differential mode surge transient 1000 Vdc
No errors. IEEE C62.41 defined pulse transient Common mode surge
(1.2/50s pulse)
1000 Vdc
Conducted Immunity Error free per EN/IEC 61000-4-6 Level 3 (10Vrms).
Reliability (calculated) 400,000 Hours
At ambient of 25°C at full load per Telcordia SR-332, Reliability
Prediction for Electronic Equipment, Method I Case III.
Isolation
Input-Chassis/Signals
Input-Output/Signals
Output-Chassis/Signals
Main-Aux Outputs
1700
2250
2250
2250 Vdc
Per EN60950.
Per IEEE802.3af.
Service Life 10 Years 25°C ambient, full load excluding fans.
Acoustic Noise 55 dBA Noise is proportional to fan speed, load and ambient temperature.
4 Designed to start at an ambient as low as -40°C, but may not meet operational limits until above -5°C.
5 Radiated emissions compliance was met using a Lineage Power shelf. This shelf includes output common and differential mode capacitors that
assist in meeting compliance.
