GW-7472 User Manual, Version 1.0, Dec 2010 --- 9
2. Hardware Information
2.1 Specifications
Model GW-7472
System
CPU
32-bit MCU
Communication Interface
Ethernet
10/100 Base-TX, 8-pin RJ-45 x 1,
(Auto-negotiating, Auto-MDI/MDIX, LED indicator)
PoE (IEEE 802.3af, Class 1)
COM1
2-wire RS-485 / 4-wire RS-422
Self-Tuner Yes, automatic RS-485 direction control
UART 16c550 or compatible
COM Port Format
Baud Rate 1200 to 115200 bps.
Data Bit 7, 8
Parity None, Odd, Even
Stop Bit 1, 2
General
Power Input
PoE: IEEE 802.3af, Class 1
DC jack: +12 ~ 48 V
DC
Power Consumption 0.05 A @ 24 VDC
Connector 10-Pin Removable Terminal Block x 1
Mounting DIN-Rail
Flammability Fire Retardant Materials (UL94-V0 Level)
Operating Temperature -25° ~ 75°C
Storage Temperature -30° ~ 80°C
Humidity 10 ~ 90% RH, non-condensing
