GW-7472 User Manual, Version 1.0, Dec 2010 --- 42
Appendix A: EtherNet/IP Object Model
1. Device Object Model
The Device Object Model is the logical organization of attributes, classes and services
supported by a device. Objects are composed of attributes and services. There are three
types of objects in any CIP device: Required Objects, Application Objects and Vendor
Specific Objects.
Required Objects are object classes that must be supported by all devices on EtherNet/IP.
Applications Objects are classes that must be supported by all devices using the same
profile. An example of a profile is a Discrete I/O device or an AC Drive. This ensures that
devices from different vendors but with the same profile have a common interface to
EtherNet/IP Client devices. For example, every AC Drive device must have a motor object
among its required application objects. The attribute numbers for the maximum motor
frequency and other motor data are predefined by the AC Drive profile to simply access to
any device supporting the AC Drive profile.
Vendor Specific Objects are classes that add attributes and s ervices that don’t fit into the
Required or Application Objects.
The required objects of the GW-7472 are list as below:
 Identity Object (0x01)
 Message Router Object (0x02)
 Assembly Object (0x04)
 Connection Manager Object (0x06)
 TCP Object (0xF5)
 Ethernet Link Object (0xF6)
