GW-7472 User Manual, Version 1.0, Dec 2010

--- 53

9. Connection Manager Service Request Error Codes

Reference Volume 1: CIP Common Specification Table 3-5.29

General

Status (in

hex)

Extended

Status

(in hex)

Explanation and Description

Service completed successfully

100

CONNECTION IN USE OR DUPLICATE FORWARD OPEN
This extended status code shall be returned when an originator is trying to
make a connection to a target with which the originator may have already
established a connection

103

TRANSPORT CLASS AND TRIGGER COMBINATION NOT SUPPORTED
A transport class and trigger combination has been specified which is not
supported by the target. Routers shall not fail the connection based on the
transport class and trigger combination. Only targets shall return this extended
status code.

106

OWNERSHIP CONFLICT
The connection cannot be established since another connection already "owns"
some of the resources required for this connection.

107

CONNECTION NOT FOUNT AT TARGET APPLICATION
This extended status code shall be returned by the close connection request,
where the connection which is to be closed is not active at the target node.

108

INVALID NETWORK CONNECTION PARAMETER
This extended status code shall be returned as the result of specifying a
connection type, connection priority, redundant owner or fixed / variable that is
not supported by the target application. Only a target node shall return this
extended status code.

109

INVALID CONNECTION SIZE
This extended status code is returned when the target or router does not
support the specified connection size.

113

CONNECTION MANAGER CANNOT SUPPORT ANY MORE CONNECTIONS

114

VENDOR ID OR PRODUCT CODE MISMATCH
The Product Code or Vendor Id specified in the electronic key logical segment
does not match the Product Code or Vendor Id of in the target device.

115

PRODUCT TYPE MISMATCH
The Product Type specified in the electronic key logical segment does not
match the Product Type of in the target device.

116

REVISION MISMATCH
The major and minor revision specified in the electronic key logical segment
does not correspond to a valid revision of the target device.

117

INVALID CONNECTIO POINT
The connection point specified in the connection path does not correspond to a
valid connection point for the target application.

118

INVALID CONFIGURATION FORMAT
An instance number specified for the configuration data does not correspond to
a configuration instance.

119

CONNECTION REQUEST FAILS SONCE THERE IS NO CONTROLLING
CONNECTION CURRENTLY OPEN
The extended status code shall be returned when an attempt is made to
establish an echo (i.e. listen only) connection to a connection which has no
controlling connection (i.e. owner).

11A

TARGET APPLICATION CANNOT SUPPORT ANY MORE CONNECTIONS
The maximum number of connections supported by this instance of the Target
