GW-7472 User Manual, Version 1.0, Dec 2010 --- 49
6. TCP/IP Interface Object (F5
hex
)
The TCP/IP Interface Object contains read-only data that describes the TCP/IP connection
parameters between the Gateway and the EtherNet/IP scanner. The configurable items
include the GW-7472
’s IP address, network mask and gateway address. You can’t directly
control any attributes of this object.
Class Attributes (Instance ID = 0
hex
)
Instance Attributes (Instance ID = 1
hex
)
Attribute ID Name Data Type Data Value Access Rule
1 Revision UINT 01
dec
Get
2 Max Instance UINT 01
dec
Get
3 Number of Instances UINT 01
dec
Get
6
Max Class Attributes ID
Number
UINT 07
dec
Get
7
Max Instance Attributes
ID Number
UINT 06
dec
Get
Attribute ID Name Data Type Data Value Access Rule
1 Status
1
UINT 01
dec
Get
2 Configuration Capability
2
UINT 04
dec
Get
3 Configuration Control
3
UINT 00
dec
Get
4
Physical Link Object
4
Structure of:
Path Size
Path
UINT
Padded EPATH
02
dec
20F6
hex
, 2401
hex
Get
5
Interface Configuration
5
Structure of:
IP Address
Network Mask
Gateway Address
Name Server
Name Server 2
Domain Name Size
Domain Name
UINT
UINT
UINT
UINT
UINT
UINT
UINT 192 168 255 1
dec
255 255 0 0
dec
192 168 0 1
dec
0
0
0
0
Get
6
Host Name
6
Structure of:
Host Name Size
Host Name
UINT
String
0
0
Get
