GW-7472 User Manual, Version 1.0, Dec 2010

--- 28

4.2.1.1 Manually Configuration

In manually configuration, you have to assign all the network settings by yourself. The steps are

shown below:

Step1: Select the

“Static IP”.

Step2: Enter the network settings.

Step3: Click the

“Update Settings” button to finish the configuration.

4.2.1.2 Dynamic Configuration

The procedure of the dynamic configuration is very easy. If you have a DHCP server, network

address can be configured dynamically by the following steps:

Step1: Select the “DHCP”.

Step2: Click the

“Update Settings” button to finish the configuration.
