GW-7472 User Manual, Version 1.0, Dec 2010 --- 29
4.2.2 Serial Port Settings
There four parameters in the serial port configuration dialog.
Item Descriptions:
Item Description Default
Baud Rate (bps)
Set bard rate of the RS-485/422 ports. 115200
Data Size (bits)
Set data size of the RS-485/422 ports. 8
Parity
Set parity of the RS-485/422 ports. None
Stop Bits (bits)
Set stop bits of the RS-485/422 ports. 1
Step1: Enter the port settings.
Step2: Click the
“Update Settings” button to finish the configuration
